ASA on Voron Trident

Nozzle Temp

250 °C

Range: 240 – 260 °C

Bed Temp

110 °C

Range: 100 – 120 °C

Print Speed

50

mm/s · max 60

Layer Height

0.20

mm · max 0.28

Fan Speed

10 %

1st layer: 0 %

1st Layer Speed

20

mm/s

Retraction

0.7 mm

@ 45 mm/s

Nozzle Type

Brass

Standard

Retraction Note

• Treat it like ABS in the Voron. The enclosed chamber handles ASA excellently.

Settings

Recommended

Range

Nozzle Temperature

250 °C

240 – 260 °C

Bed Temperature

110 °C

100 – 120 °C

Print Speed

40 – 60 mm/s

up to 60 mm/s on this printer

First Layer Speed

20 mm/s

slower is better for adhesion

Layer Height

0.16 – 0.24 mm

0.12 – 0.28 mm

Fan Speed (Normal)

0 – 20 %

–

Fan Speed (1st Layer)

0 %

–

Retraction Distance

0.7 mm

Direct drive

Retraction Speed

45 mm/s

–

Nozzle Type

Brass (standard)

Brass is fine; hardened optional

Dry Filament

80 °C for ≥ 5 h

print from a dry box in humid weather

Enclosure

Required, built in

Required, this printer is enclosed

Support Material

HIPS, ASA (self-supporting)

–

Printing Notes

ASA is the outdoor material. It holds colour and impact strength under Australian UV where ABS chalks and yellows within a season.

It is more impact-resistant than ABS, 19 – 20 kJ/m² against 7 – 10.5, and warps slightly less, but it still needs an enclosure.

Klipper's pressure advance does most of the ooze control on a Trident, so short fast retraction beats long slow retraction here.

As a self-built machine the Trident's chamber temperature is whatever you have built it to hold, so check it before starting a high-temperature print rather than assuming.

Slicer: OrcaSlicer / SuperSlicer (Klipper). Dry the filament at 80 °C / ≥ 5 h before a long print. Every figure above assumes dry filament.

Troubleshooting

Warping despite an enclosure. ASA runs hotter than ABS. Take the bed to the top of what your machine allows and let the chamber come up to temperature before the print starts, not during it.

Weak layer bonding. Cooling is on. ASA wants the fan off entirely except for bridges.

Surface blistering or bubbling. Damp filament. Dry at 80 °C for at least five hours. ASA's listed moisture absorption is 0.35 % at 23 °C and 50 % relative humidity, at equilibrium.
