Technical Specifications
Product Specifications
- Filament weight
- 1 kg
- Filament diameter
- 1.75 mm
- Dimensional tolerance
- ±0.03mm
- Spool weight (empty)
- 150 g
- Spool weight (new)
- 1.15 kg
- Spool diameter outer
- 200 mm
- Spool diameter inner (hub)
- 52 mm
- Spool width
- 65 mm
- Package weight
- 1.3 kg
- Package dimensions
- 210mm x 220mm x 75mm
- Drying recommendation
- 70°C for a minimum of 5 hours using a filament dryer / food dehydrator.
- Storage recommendation
- Airtight bag or container with desiccant in a cool, dark and dry area to prevent moisture absorption. For optimal long term storage we recommend drying the filament prior to sealing the filament spool in a vacuum bag with desiccant.
Print Parameters
- Nozzle temperature
- 210°C - 230°C
- Bed temperature
- 50°C - 70°C
- Printing speed
- 40mm/s - 60mm/s
- Support material
- PVA , PLA (as support interface)
Mechanical Properties
- Tensile strengthISO 527
- 41~45 MPa
- Elongation at breakISO 527
- 10~12 %
- Tensile modulusISO 527
- 1400~1500 MPa
- Flexural strengthISO 178
- 64~66 MPa
- Impact strengthISO 180
- 5~6 kJ/m²
Physical Properties
- DensityISO 1183
- 1.27~1.28 g/cm³
- Melt flow rate (220°C/2.16 kg)ISO 1133
- 8~12 g/10min
- Moisture absorption (23°C/24h)ISO 62
- <0.2 %
Thermodynamic Properties
- HDT @ 0.455 MPa (66 psi)ISO 75
- 68 °C
- Continuous use temperatureIEC 60216
- 65 °C
Colour Hex Codes
- Green #05AA3D
- Orange #FF8A00
- Blue #005BD3
- Purple #A54DCF
- Red #F61F1F
Approximate values taken from the colour swatches. Screen colours are a guide only.
