Technical Specifications
Product Specifications
- Filament weight
- 1 kg
- Filament diameter
- 1.75 mm
- Dimensional tolerance
- ±0.05mm
- Spool weight (empty)
- 150 g
- Spool weight (new)
- 1.15 kg
- Spool diameter outer
- 200 mm
- Spool diameter inner (hub)
- 52 mm
- Spool width
- 65 mm
- Package weight
- 1.3 kg
- Package dimensions
- 210mm x 220mm x 75mm
- Drying recommendation
- 100°C for a minimum of 5 hours using a filament dryer / food dehydrator.
- Storage recommendation
- Airtight bag or container with desiccant in a cool, dark and dry area to prevent moisture absorption. For optimal long term storage we recommend drying the filament prior to sealing the filament spool in a vacuum bag with desiccant.
Print Parameters
- Nozzle temperature
- 260°C - 290°C (280°C recommended)
- Bed temperature
- 70°C - 100°C (90°C recommended)
- Printing speed
- 40mm/s - 150mm/s (80mm/s recommended)
- Support material
- Self Supported
Mechanical Properties
- Tensile strengthISO 527
- 75~85 MPa
- Elongation at breakISO 527
- 4~5 %
- Tensile modulusISO 527
- 4500~5000 MPa
- Flexural strengthISO 178
- 140-150 MPa
- Impact strengthISO 180
- 25~30 kJ/m²
Physical Properties
- DensityISO 1183
- 1.3~1.31 g/cm³
- Melt flow rateISO 1133
- 3~6 g/10min
- Moisture absorption (23°C/24h)ISO 62
- <0.3 %
Thermodynamic Properties
- HDT @ 0.455 MPa (66 psi)ISO 75
- 205 °C
Colour Hex Codes
- Carbon Fibre Black #000000
Approximate values taken from the colour swatches. Screen colours are a guide only.
