PLA+ · Full Settings Reference
Danielle A.
OZFDM PLA+
Full Settings Reference
Setting |
Recommended |
Range |
|---|---|---|
| Nozzle Temperature | 210–220°C | 190–230°C |
| Bed Temperature | 50–60°C | 25–60°C |
| Print Speed | 60–90 mm/s | Up to 120 mm/s |
| First Layer Speed | 20–40 mm/s | Slower for adhesion |
| Layer Height | 0.12–0.24 mm | 0.08–0.32 mm |
| Fan Speed (normal) | 100% | – |
| Fan Speed (first layer) | 0–30% | – |
| Retraction Distance | 0.8–1.2 mm | – |
| Retraction Speed | 35–45 mm/s | – |
| Nozzle Type | Brass (standard) | Hardened optional |
| Dry Filament | Recommended | Especially in humid conditions |
| Enclosure | Not required | Optional for consistency |
Printing Notes
- PLA+ prints easily across most machines and is forgiving for beginners
- Start with a standard PLA profile, then fine tune temperatures for your specific printer
- Lower first layer speeds improve adhesion and reduce warping
- Keep filament dry for best surface finish and layer bonding
Mechanical Properties
| Property | Value |
|---|---|
| Tensile Strength | 45.5–49 MPa |
| Elongation at Break | 14.5–16.5% |
| Flexural Modulus | 950–1050 MPa |
| Flexural Strength | 73–76 MPa |
| Impact Strength | 9.5–10.5 kJ/m² |
Thermodynamic Properties
| Property | Value |
|---|---|
| Heat Deflection Temperature | ~53°C |
| Continuous Use Temperature | ~50°C |
Physical Properties
| Property | Value |
|---|---|
| Density | 1.25–1.26 g/cm³ |
| Melt Flow Rate (MFR) | 3–6 g/10 min (250°C / 2.16kg) |
| Moisture Absorption (24h) | <0.3% |
Filament Specifications
| Property | Value |
|---|---|
| Filament Weight | 1kg |
| Filament Diameter | 1.75mm |
| Dimensional Tolerance | ±0.03mm |
| Spool Weight (empty) | 150g |
| Spool Weight (full) | ~1.15kg |
| Spool Outer Diameter | 200mm |
| Spool Inner Diameter | 52mm |
| Spool Width | 65mm |
| Package Weight | ~1.3kg |
| Package Dimensions | 210 × 210 × 75 mm |
Material Handling
- Drying Recommendation: 40–45°C for 4–6 hours using a filament dryer or food dehydrator
- Storage recommendation: Store in a sealed bag or container with desiccant in a cool, dry environment. For long term storage, keep filament vacuum sealed.
OzFDM PLA+ Filament
Premium PLA+ in 16 colours. Easy to print, reliable results every time.
