PA-CF (Carbon Fibre Nylon) on Bambu Lab X1 Carbon

 Nozzle Temp

280 °C

Range: 270 – 290 °C

Bed Temp

80 °C

Range: 60 – 90 °C

Print Speed

50

mm/s · max 60

Layer Height

0.20

mm · max 0.28

Fan Speed

10 %

1st layer: 0 %

1st Layer Speed

20

mm/s

Retraction

0.9 mm

@ 30 mm/s

Nozzle Type

Hardened

Fitted as standard

  Retraction Note

• Minimal retraction. A hardened nozzle is mandatory – PA-CF will wreck brass nozzles quickly.

 Settings

Recommended

Range

Nozzle Temperature

280 °C

270 – 290 °C

Bed Temperature

80 °C

60 – 90 °C

Print Speed

50 mm/s

up to 60 mm/s on this printer

First Layer Speed

20 mm/s

slower is better for adhesion

Layer Height

0.16 – 0.24 mm

0.12 – 0.28 mm

Fan Speed (Normal)

0 – 20 %

–

Fan Speed (1st Layer)

0 %

–

Retraction Distance

0.9 mm

Direct drive

Retraction Speed

30 mm/s

–

Nozzle Type

Hardened steel

Required — fitted as standard on this printer

Dry Filament

80 °C for ≥ 12 h

print from a dry box in humid weather

Enclosure

Required — built in

Required — this printer is enclosed

Support Material

PVA

–

 Printing Notes

PA6-CF is the strongest filament OzFDM sells — 60 – 65 MPa tensile and a 4900 – 5000 MPa flexural modulus, with a 200 °C heat deflection temperature.

It demands a hardened nozzle, a hot chamber and genuinely dry filament. Treat any one of those as optional and the print will fail.

The X1C ships with a hardened steel nozzle and a fully enclosed chamber, so it needs none of the modifications other machines do for this material.

Bambu Studio's own generic profile is a reasonable starting point, but its temperatures are set for Bambu filament — use the figures above for OzFDM spools.

Slicer: Bambu Studio / OrcaSlicer. Dry the filament at 80 °C / ≥ 12 h before a long print — every figure above assumes dry filament.

 Troubleshooting

Steam, popping and a furry surface — PA6 absorbs about 1 % moisture. Dry twelve hours at 80 °C and feed from a sealed dry box during the print.

Layers separating under load — Nozzle too cool for the speed. Push to 290 °C and slow to 40 mm/s — layer bonding in nylon is heat-driven.

Parts distorting after they come off the bed — PA6 continues to absorb moisture and grows slightly. Anneal, then condition the part before measuring it.
